Complete Can Filling
Production Line
Grandvow provides complete can filling production line solutions. The cans filling production line is mainly used for the washing, filling and capping of tinplate, aluminum alloy, and other cans. The can filler machine is used in carbonated drinks, juice drinks, beer, etc.
Can Filling Machine by Liquid
Whether formal batches or industrialcan fling lines: Choosing the right can flling machine determines quality,efciency and ong:term proftabity. Our can filling solutions for a wide range of reguirements - made in Germany and with state-of-the-art technology.
Carbonated Drinks
Thick Sauce
Beer Beverages
Juice Beverages
Can Filler Description
Can Filling Machine For
Carbonated Drinks/Beer/Juice/Pet Food/Tomato Sauce
- Designed for Versatility: Capable of filling a diverse range of liquid products, including purified water, high-carbonation beverages, beers, ready-to-drink (RTD) coffees, juices, and viscous products like sauces and pastes.
- Broad Container Compatibility: Seamlessly meets the filling demands for various can types and materials, including aluminum can, three-piece cans, two-piece cans, tinplate.
Can Filling Machine
Sauce Can Filling Machine
Sauce can filling machine can fill semi-solid liquids, including ketchup, peanut butter, dog food, etc.
Juice Can Filling Machine
juice can filling machine can fill various juices, fruit teas, tea drinks, etc.
Carbonated Drinks Can Filling Machine
Carbonated drinks can filling machine is suitable for filling beer, carbonated drinks, soda, etc.
Complete Can Filling Production Line Solution
Beverage Processing System
Water Treatment System
Empty Can De-Palletizer
Can Rinser
Filling Part
Conveyor System
Packaging System
Palletizing System
Can Filling Machine Parameter
| Modle | Applicable Products | Capacity (CPH) | Can Volume (ML) | Can Diameater (MM) | Can High (MM) | Cover Diameter (MM) | Machine power (Kw) | Machine size (MM) (L*W*H) |
|---|---|---|---|---|---|---|---|---|
| N6-1 | Beer & Carbonated Beverages | 1500 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 3 | 2100*1500*2000 |
| N6-2 | Beer & Carbonated Beverages | 3000 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 4 | 2700*1700*2350 |
| N12-4 | Beer & Carbonated Beverages | 6000 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 4 | 2700*1700*2350 |
| N20-4 | Beer & Carbonated Beverages | 12000 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 4 | 3300*2100*2350 |
| N30-6 | Beer & Carbonated Beverages | 18000 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 10 | 5000*2800*2300 |
| N45-8 | Beer & Carbonated Beverages | 24000 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 10 | 5200*3200*2300 |
| N60-8 | Beer & Carbonated Beverages | 36000 | 200-1000 | Φ57.4-Φ84 | 65-168 | Φ57-Φ64.82 | 13 | 5400*3400*2300 |
